Routing across Knative Services

This example shows how to map multiple Knative services to different paths under a single domain name using the Istio VirtualService concept. Since Istio is a general-purpose reverse proxy, these directions can also be used to configure routing based on other request data such as headers, or even to map Knative and external resources under the same domain name.

In this sample, we set up two web services: "Search" service and "Login" service, which simply read in an env variable 'SERVICE_NAME' and prints "${SERVICE_NAME} is called". We'll then create a VirtualService with host "example.com", and define routing rules in the VirtualService so that "example.com/search" maps to the Search service, and "example.com/login" maps to the Login service.

Prerequisites

1. Install Knative
2. Install docker
3. Acquire a domain name. In this example, we use example.com. If you don't have a domain name, you can modify your hosts file (on Mac or Linux) to map example.com to your cluster's ingress IP.

Setup

Build the app container and publish it to your registry of choice:

REPO="gcr.io/<your-project-here>"

# Build and publish the container, run from the root directory.
docker build \
  --tag "${REPO}/serving/samples/knative-routing-go" \
  --file=serving/samples/knative-routing-go/Dockerfile .
docker push "${REPO}/serving/samples/knative-routing-go"

# Replace the image reference with our published image.
perl -pi -e "s@github.com/knative/docs/serving/samples/knative-routing-go@${REPO}/serving/samples/knative-routing-go@g" serving/samples/knative-routing-go/*.yaml

# Deploy the Knative Serving sample
kubectl apply -f serving/samples/knative-routing-go/sample.yaml

Exploring

A shared Gateway "knative-shared-gateway" is used within Knative service mesh for serving all incoming traffic. You can inspect it and its corresponding k8s service with

# Check shared Gateway
kubectl get Gateway -n knative-serving -oyaml

# Check the corresponding k8s service for the shared gateway
kubectl get svc knative-ingressgateway -n istio-system -oyaml

And you can inspect the deployed Knative services with

kubectl get service.serving.knative.dev

You should see 2 Knative services: search-service and login-service.

You can directly access "Search" service by running

# Get the ingress IP.
export GATEWAY_IP=`kubectl get svc knative-ingressgateway -n istio-system -o jsonpath="{.status.loadBalancer.ingress[*]['ip']}"`

export SERVICE_HOST=`kubectl get route search-service -o jsonpath="{.status.domain}"`

curl http://${GATEWAY_IP} --header "Host:${SERVICE_HOST}"

You should see

Search Service is called !

Similarly, you can also directly access "Login" service with

# Get the ingress IP.
export GATEWAY_IP=`kubectl get svc knative-ingressgateway -n istio-system -o jsonpath="{.status.loadBalancer.ingress[*]['ip']}"`

export SERVICE_HOST=`kubectl get route login-service -o jsonpath="{.status.domain}"`

curl http://${GATEWAY_IP} --header "Host:${SERVICE_HOST}"

You should see

Login Service is called !

Apply Custom Routing Rule

You can apply the custom routing rules defined in "routing.yaml" file with

kubectl apply -f serving/samples/knative-routing-go/routing.yaml

The routing.yaml file will generate a new VirtualService "entry-route" for domain "example.com". You can see it by running

kubectl get VirtualService entry-route -o yaml

Now you can send request to "Search" service and "Login" service by using different URI.

# Get the ingress IP.
export GATEWAY_IP=`kubectl get svc knative-ingressgateway -n istio-system -o jsonpath="{.status.loadBalancer.ingress[*]['ip']}"`

# send request to Search service
curl http://${GATEWAY_IP}/search --header "Host:example.com"

# send request to Login service
curl http://${GATEWAY_IP}/login --header "Host:example.com"

You should get the same results as you directly access these services.

How It Works

This is the traffic flow of this sample:

When an external request with host "example.com" reaches "knative-shared-gateway" Gateway, the "entry-route" VirtualService will check if it has "/search" or "/login" URI. If it has, then the host of request will be rewritten into the host of "Search" service or "Login" service correspondingly, which actually resets the final destination of the request. The request with updated host will be forwarded to "knative-shared-gateway" Gateway again. The Gateway proxy checks the updated host, and forwards it to "Search" or "Login" service according to its host setting.

Cleaning up

To clean up the sample resources:

kubectl delete -f serving/samples/knative-routing-go/sample.yaml

kubectl delete -f serving/samples/knative-routing-go/routing.yaml
